PULL UNDERGROUND PIPE AND CABLE QUICKLY AND EASILY WITH “MAXI-GRIP”® PIPE AND CABLE PULLERS.
|
| Design Features |
| Lost Motion Assembly |
Solid Steel Nose Cone |
Plow Steel Mesh Grip
(Replaceable) |
So unique they earned U.S. Patent No. 4,969,677
BorePro’s Maxi-Grips are durable and economical tools designed for pulling underground pipe and cable with speed and ease. Maxi-Grips consist of two primary components - a uniquely designed steel nose cone device and a heavy duty plastic coated galvanized steel mesh grip. Six models enable contractors to pull pipe and cable from 1/2 inch to 4 1/2inch outside diameters.
Provides the contractor with greater flexibility, convenience, and durability!
Unique nose cone design provides the user with several economic and time saving benefits not found in any other pulling device on the market today. First, each Maxi-Grip accommodates multiple sizes of pipe and cable, thereby minimizing contractor tooling costs. Second, the tapered nose cone provides a large, smooth compacted boring for pipe and cable to follow, thus reducing friction and allowing longer pulls. Also, the large boring eliminates cable “looping” when boring under walkways and driveways. Third, the nose cone design eliminates the need to seal pipe opening against outside contamination. The user merely slips the pipe into the nose cone and pulls the pipe - a real time saver. Fourth, since the mesh grips are mounted inside the nose cone, they last up to five times longer.
Pipe and cable are easily inserted - quickly removed.
|
"Maxi-Grip"® Pipe and Cable Pullers |
 |
| Spring Pin Set |
Mesh Grip |
|
| Maxi-Grip With Mesh Grip |
Replacement Mesh Grips |
Spring Pin Set (2 Pcs.) |
Working
Load
Lbs. |
Breaking
Strength
Lbs. |
| Model No. |
Outside
DIa. |
Pipe Size |
Grip Range |
Model No. |
Model No. |
MG-100A
|
1.875" |
1/2" - 3/4" |
.75" - 1.25" |
A-20 |
SP-100 |
2,000 |
6,000 |
MG-100B
|
1.875" |
3/4" - 1" |
1.050" - 1.400" |
B-24 |
SP-100 |
2,500 |
7,500 |
MG-125A
|
2.375" |
3/4" - 1 1/4" |
1.050" - 1.800" |
B-24 |
SP-125 |
2,500 |
7,500 |
MG-200A
|
3.0" |
1 1/2" - 2" |
1.75" - 2.375" |
C-26 |
SP-200 |
3,500 |
10,500 |
MG-300E*
|
4.5" |
2 1/2" - 3" |
2.75" - 3.5" |
D-38 |
SCS-4
(Bolt) |
4,500 |
13,500 |
MG-400E*
|
5.5" |
3 1/2" - 4" |
4.0" - 4.5" |
F-52 |
SCS-5
(Bolt) |
6,000 |
18,000 |
*Equipped with Forged Eye. |
|
Maxi-Grip
without Mesh Grip |
| Model No. |
O.D. |
| MG-100Z |
1.875" |
| MG-125Z |
2.375" |
| MG-200Z |
3.000" |
| *MG-300Z |
4.500" |
| *MG-400Z |
5.500" |
|
MAXI-GRIP® without Mesh Grip |
Swivel-Eye Maxi-Grip® |
 |
BorePro's Swivel-Eye Maxi-Grips are designed to help relieve the twisting forces that are created when pulling pipe and cable underground. Today, they are being used extensively in the Directional Boring Industry to relieve destructive pulling torque on pipe and cable.
All Swivel-eye assemblies are custom manufactured by BorePro from Forged Carbon and Alloy Steels that are Heat-Treated to ASTM Standards for strength and wear resistance.
Swivel-Eye assemblies are attached to Maxi-Grips, both mechanically by thread and MIG welding, to insure maximum tensile strength and service life.
NOTICE: Do not push rearward when directional boring. You may crush pulling eye.
|
Swivel-eye Maxi-Grips
with Mesh grip
|
| Model No. |
Pipe size |
| MG-100AS |
1/2" - 3/4" |
| MG-125AS |
3/4" - 1" |
| MG-100BS |
3/4" - 1 1/4" |
| MG-200AS |
1 1/2" - 2" |
| MG-400ES |
2 1/2" - 3" |
| MG-300ES |
3 1/2" - 4" |
|
|
|
|
